BC723
Electrical to Optical Transceivers For Control
Description
The BC723 is a compact stand-alone multi-format converter for control signals. Control data and GPI signals are transmitted over a pair of fibres.The BC723 can be supplied in multimode, singlemode and CWDM variations to suit all applications and is a perfect complement to video converter cards. Power is provided by a DC source of 4.5 to 17V via a 4 pin XLR or the Bluebell PS12 in-line power adapter.
The BC723 version fits in Bluebell 19” rack frames. Please contact the Sales Office for more information.
For applications requiring analogue audio in addition to serial control data, the BC623 is available.
Specification
| General Card Specification | |
| Depth | 92 mm |
| Width | 64 mm |
| Height | 30mm Excluding Connectors |
| Weight | 100 g |
| Operating Temp | -30 to 70”c |
| Power | 2.5 W |
| Conformance | |
| EMI/RFI | Complies with 89/336/EEC, EN55022B, EN61000-4-2, EN61000-4-4(level 2), EN61000-4-4FTB, EN61000-4-5 EN61000-411 |
| Electrical | Complies with EN61000-6-1
EN61000-6-2, EN61000-6-3, EN61000-6-4 |
| Laser Safety | Dependent on SFP fitted
Complies with Class 1 laser product |
| RoHS | Complies with Directive 2002/95/ec |
| Warranty | 5 Years |
| Electrical Input | |
| Connector | 44 Pin D connector |
| Format | 20 Hz-20 kHz± 0.3 dB
2 x RS232 Bi-Directional 2 x RS422/485 Bi-Directional 2 x GPI Bi-Directional |
| Optical Output | |
| Connector | 1x female LC as standard per channel |
| Tx wavelength and power plus receive sensitivity are defined by the SFP fitted
Typical values are outlined below TX Power: -2dBm@1310nm (typical) -2dBm@1510nm (typical) 0 dBm@CWDM (typical)
RX Wavelength 1200-1610 nm RX Sensitivity > [email protected] Gb/s Max I/P power > -1 dBm |
|
Related products
Ordering info
| BC723/M | Multimode Data Fibre Optic Transceiver Module. 2 x RS232, 2 x RS422/485 and 2 x GPI over 2
fibres. Fitted with LC connectors. |
| BC723/S/13/WB | Singlemode Data Fibre Optic Transceiver Module. 2 x RS232, 2 x RS422/485 and 2 x GPI over 2 fibres. (1310 nm TX and Wideband receiver). Fitted with LC connectors. |
| BC723/S/13/15 | Singlemode Data Fibre Optic Transceiver Module. 2 x RS232, 2 x RS422/485 and 2 x GPI over 1 fibre. (1310 nm TX). Used in conjunction with BC623/2/15/13 as a matched pair. Fitted with LC connectors. |
| BC723/S/15/13 | Singlemode Data Fibre Optic Transceiver Module. 2 x RS232, 2 x RS422/485 and 2 x GPI over 2 fibres. (1550 nm TX). Used in conjunction with BC623/S/13/15 as a matched pair. Fitted with LC connectors. |
| BC723 | Data Fibre Optic Transceiver Base Module. 2 x RS232, 2 x RS422/485 and 2 x GPI over fibre. No Optics Fitted. |
| BC723/S/CWDM/xx/WB | Singlemode and Data Fibre Optic Transceiver Module. 2 x Rs232, 2 x RS422/485 and 2 x GPI over 2 fibres. (CWDM TX and Wideband receiver). Fitted with LC connectors. |
